DB Electrical 430-22011 Tilt & Trim Motor Compatible with/Replacement for Mercury Marine All Models All 828708, 828708T, 878265A1, 878265A4, 8M0031551, T1082M, 67-2802, 4-1254, P220N, 6250, 10826N
Product details
| Management number | 228711887 | Release Date | 2026/05/31 | List Price | $23.20 | Model Number | 228711887 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
POWER TRIM MOTOR For MERCURY MARINE==MERCURY Marine==TILT & TRIM All Models 135 H.P.TILT & TRIM All Models 150 H.P.TILT & TRIM All Models 175 H.P.TILT & TRIM All Models 200 H.P.TILT & TRIM All Models 225 H.P.Specifications:Voltage:12 VoltsRotation:ReversibleField Hsg OD:75mm / 2.953inOverall Length:124.7mm / 4.909inShaft OD:8mm / 0.315inShaft Notes:Tanged ShaftApproximate Weight:3.46 lbs / 1.57 kgNotes:(2) 6.5mmID Mounting Holes, (2) 3-1/2 Foot Long Wire Harness With Bullet Connectors, 1/4" Mounting HolesReplaces these part numbers:API MARINEPT486NMARCO MARINE6250LESTER10826MERCURY MARINE828708, 828708T, 878265A1, 878265A4MES MOTORCYCLE & MARINET1082MSIERRA MARINE18-6773SPIDER MARINETM10826
- Specs: Description: Tilt & Trim Motor, Voltage: 12, Rotation: RE
- Replaces OEM Numbers: Mercury Marine 828708, 828708T, 878265A1, 878265A4, 8M0031551, MPA Small Motor P220N, NAPA Small Motor RN10826, Wilson 94-35-1019, Wilson Small Engine 74-35-10826, WAI 10826N, WAI (OLD) 82-7867, Sierra Marine 18-6773, Remy Small Motor RT05005, RCP 26250A, MP Parts 4-1254, Mallory 9-18204, EMS 49-6250, EMP Parts 4-6773, Dixie TM-513, Barsanco 540-10826
- Compatible With/Replacement For: Mercury Marine All Models All
- 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
- 100% New aftermarket Tilt & Trim Motor built to meet OEM specifications for Mercury Marine
| UPC | 701485537653 |
|---|---|
| ASIN | B019GUJVAY |
| Voltage | 12 Volts |
| Fuel Type | Gasoline |
| Brand Name | DB Electrical |
| Engine Type | 4 Stroke |
| Item Weight | 3.57 Pounds |
| Manufacturer | DB Electrical |
| Model Number | 430-22011 |
| Material Type | Aluminum |
| Mounting Type | Engine Mount |
| Maximum Horsepower | 225 Horsepower |
| Included Components | Tilt Trim Motor |
| Manufacturer Part Number | 430-22011 |
| OEM Equivalent Part Number | 828708, 8M0031551, 6250, or others listed in 'bullet_point bp2' |
| Recommended Uses For Product | For Salt Water |
| Global Trade Identification Number | 00701485537653 |
| EU Spare Part Availability Duration | 1 Years |
